Description
Photometric Diagrams
System watts : 25W / 35W / 58W
Efficacy (LPW): 110LPW
Input Voltage: AC100-277V / AC347-480V for option
Colour temp (K): 2200K / 2700K / 3000K / 4000K / 5000K / 6000K
Colour Rendering Index (CRI): Ra>70 as standard
Light distribution: Type V
IP Rating: IP66
IK Rating: IK08
Dimming Option: 1-10V, Timmer Programmable, DALI Dimming
Sensor Option: Photocell on/off, Photocell Dimming, Microwave Motion Sensor, PIR Sensor
Surge Protion: 6KV
Fixture Colour: Grey (RAL9007)
Operating temp (°C): -40~45°C
Mounting: Post top Spigot : 60mm / 76mm / 89mm as adaptor
Net Weight: 8.8kg
Warranty: Standard 5 years
