Pole & Accessories
Standard Poles 3m – 12m
Rag Bolts and Former Plates
Footing Cages
| Pole Height & Type | Part Number | Drawings | Rag Bolt & Former | Part Number | Drawings | Footing Cage | Part Number | Drawings |
|---|---|---|---|---|---|---|---|---|
| 3m Medium Duty | F3P3T-FL-MD | Download PDF | 4 x M16-276-PCD | RBF-4M16-276 | Download PDF | Footing Cage 4 x M16 – 276mm PCD to suit 600 DIA x 800mm | PM-4-276-600-800 | Download PDF |
| 4m Medium Duty | F4P4T-FL-MD | Download PDF | 4 x M16-276-PCD | RBF-4M16-276 | Download PDF | Footing Cage 4 x M16 – 276mm PCD to suit 600 DIA x 800mm | PM-4-276-600-800 | Download PDF |
| 6m Medium Duty | F6P6T-FL-MD | Download PDF | 4 x M20-311-PCD | RBF-4M20-311 | Download PDF | Footing Cage 4 x M20 – 311mm PCD to suit 600 DIA x 1100mm | PM-4-311-600-1100 | Download PDF |
| 8m Medium Duty | F8P8T-FL-MD | Download PDF | 4 x M20-311-PCD | RBF-4M20-311 | Download PDF | Footing Cage 4 x M20 – 311mm PCD to suit 600 DIA x 1200mm | PM-4-311-600-1200 | Download PDF |
| 10m Medium Duty | F10P10T-FL-MD | Download PDF | 4 x M24-424-PCD | RBF-4M24-424 | Download PDF | Footing Cage 4 x M24 – 424mm PCD to suit 750 DIA x 1400mm | PM-4-424-750-1400 | Download PDF |
| 12m Medium Duty | F12P12T-FL-MD | Download PDF | 4 x M24-424-PCD | RBF-4M24-424 | Download PDF | Footing Cage 4 x M24 – 424mm PCD to suit 750 DIA x 1600mm | PM-4-424-750-1600 | Download PDF |
Spigot Arms
| Spigot Arms | Part Number | Drawings |
|---|---|---|
| 1 Spigot 90 degrees | SA1-90 | Download PDF |
| 2 Spigots 90 degrees | SA2-180 | Download PDF |
| 2 Spigot 180 degrees | SA2-90 | Download PDF |
| 4 Spigot 90 all 90 degrees | SA4-90 | Download PDF |
Standard Headframes
| Spigot Arms | Part Number | Drawings |
|---|---|---|
| 1 Light | HF1 | Download PDF |
| 1-2 Lights | HF2 | Download PDF |
Heavy Duty Headframes
| Headframe Brackets | Part Number | Drawings |
|---|---|---|
| 1 Light – 660mm Wide | HF1HD | Download PDF |
| 2 – 4 Lights – 1380mm Wide | HF2HD | Download PDF |
| 3 – 5 Lights – 1640mm Wide | HF3HD | Download PDF |
| 4 – 6 Lights – 2360mm Wide | HF4HD | Download PDF |
| 5 – 9 Lights – 3080mm Wide | HF5HD | Download PDF |
High Mast Poles
Rag Bolts and Former Plates
Footing Cages
| Pole Height & Type | Part Number | Drawing | Rag Bolt & Former | Part Number | Drawing | Footing Cages | Part Number | Drawing |
|---|---|---|---|---|---|---|---|---|
| 15m Medium Duty | FP15PT-FL-MD | Download PDF | 4 x M30-466 PCD | RBF-4M30-466 | Download PDF | Footing Cage 4 x M30 – 466mm PCD to suit 900 DIA. x 2300mm | PM30-4-466-900-2300 | Download PDF |
| 15m Heavy Duty | FP15PT-FL-HD | Download PDF | 8 x M30-500 PCD | RBF-8M30-500 | Download PDF | Footing Cage 8 x M30 – 500mm PCD to suit 900 DIA. x 3200mm | PM36-8-500-900-3200 | Download PDF |
| 18m Medium Duty | FP18PT-FL-MD | Download PDF | 4 x M33-538 PCD | RBF-4M33-538 | Download PDF | Footing Cage 4 x M33 – 538mm PCD to suit 900 DIA. x 2800mm | PM33-4-538-900-2800 | Download PDF |
| 20m Medium Duty | FP20PT-FL-MD | Download PDF | 4 x M33-538 PCD | RBF-4M33-538 | Download PDF | Footing Cage 4 x M33 – 538mm PCD to suit 900 DIA. x 3100mm | PM33-4-538-900-3100 | Download PDF |
| 20m Heavy Duty | FP20PT-FL-HD | Download PDF | 8 x M30-500 PCD | RBF-8M30-500 | Download PDF | Footing Cage 8 x M30 – 500mm PCD to suit 900 DIA. x 3500mm | PM30-8-500-900-3500 | Download PDF |
| 25m Medium Duty | FP25PT-FL-MD | Download PDF | 8 x M30-500 PCD | RBF-8M30-500 | Download PDF | Footing Cage 8 x M30 – 500mm PCD to suit 900 DIA. x 3500mm | PM30-8-500-900-3500 | Download PDF |
| 25m Extra Heavy Duty | FP25PT-FL-XD | Download PDF | 12 x M36-640 PCD | RBF-12M36-640 | Download PDF | Footing Cage 12 x M36 – 640mm PCD to suit 900 DIA. x 3500mm | PM36-12-640-900-3500 | Download PDF |
| 30m Medium Duty | FP30PT-FL-MD | Download PDF | 8 x M30-800 PCD | RBF-8M30-800 | Download PDF | Footing Cage 8 x M30 – 800mm PCD to suit 1200 DIA. x 3900mm | PM30-8-800-1200-3900 | Download PDF |
| 30m Heavy Duty | FP30PT-FL-HD | Download PDF | 16 x M30-800 PCD | RBF-16M30-800 | Download PDF | Footing Cage 16 x M30 – 800mm PCD to suit 1200 DIA. x 3900mm | PM30-16-800-1200-3900 | Download PDF |
| 30m Extra Heavy Duty | FP30PT-FL-XD | Download PDF | 12 x M30-860 PCD | RBF-12M30-860 | Download PDF | Footing Cage 12 x M30 – 860mm PCD to suit 1200 DIA. x 4100mm | PM30-12-860-1200-4100 | Download PDF |
| 33m Extra Heavy Duty | FP33PT-FL-XD | Download PDF | 12 x M30-860 PCD | RBF-12M30-860 | Download PDF | Footing Cage 12 x M30 – 860mm PCD to suit 1200 DIA. x 4300mm | PM33-12-860-1200-4300 | Download PDF |
